Specification
| Model | KG05 | KG06 | KG08 | KG10 | KG12 |
| Inputs | 5 | 6 | 8 | 10 | 12 |
| Mic Input channels | 1 | 2 | 4 | 6 | 8 |
| Stereo Input channels | 2 | 2 | 2 | 2 | 2 |
| Gain | MIN - MAX | MIN - MAX | MIN - MAX | MIN - MAX | MIN - MAX |
| Mic | +6dB - +50dB | +6dB - +50dB | +6dB - +50dB | +6dB - +50dB | +6dB - +50dB |
| Line | +10dB - -34dB | +10dB - -34dB | +10dB - -34dB | +10dB - -34dB | +10dB - -34dB |
| EIN | -100dB | -100dB | -100dB | -100dB | -100dB |
| Frequency response | |||||
| Mic Channel | 10Hz - 20kHz +1/-3 | 10Hz - 20kHz +1/-3 | 10Hz - 20kHz +1/-3 | 10Hz - 20kHz +1/-3 | 10Hz - 20kHz +1/-3 |
| THD Mic Channel | ?0.03% | ?0.03% | ?0.03% | ?0.03% | ?0.03% |
| Signal to noise ratio | 80dB | 80dB | 80dB | 80dB | 80dB |
| Output Levels | MAX +27(BAL) | MAX +27(BAL) | MAX +27(BAL) | MAX +27(BAL) | MAX +27(BAL) |
| MAX +22(UNBAL) | MAX +22(UNBAL) | MAX +22(UNBAL) | MAX +22(UNBAL) | MAX +22(UNBAL) | |
| Channel EQ | |||||
| Hi | 12kHz | 12kHz | 12kHz | 12kHz | 12kHz |
| Mid | 2.5kHz | 2.5kHz | 2.5kHz | 2.5kHz | 2.5kHz |
| Lo | 45Hz | 45Hz | 45Hz | 45Hz | 45Hz |
| Lo Cut | / | 80Hz | 80Hz | 80Hz | 80Hz |
| MP3/USB/SD Audio | YES | YES | YES | YES | YES |
| playback | |||||
| USB/SD Audio recording | YES | YES | YES | YES | YES |
| DSP Effects | NO | YES | YES | YES | YES |
| CEHO Effects | YES | NO | NO | NO | NO |
| Power requirements | 100V - 240V | 100V - 240V | 100V - 240V | 100V - 240V | 100V - 240V ~ |
| Dimensions (W x H x D) | 195x80x270(mm) | 227x70x359(mm) | 283x70x359(mm) | 339x70x359(mm) | 395x70x359(mm) |
-
