| MAXIMUM NUMBER OF SIMULTANEOUS EFFECTS | 9 effects or 7 effects + Amp |
| USER PATCHES | 240 |
| SAMPLING FREQUENCY | 44.1 kHz |
| A/D CONVERSION | 24-bit 128x oversampling |
| D/A CONVERSION | 24-bit 128x oversampling |
| SIGNAL PROCESSING | 32-bit |
| FREQUENCY CHARACTERISTICS | 20 Hz - 20kHz (+0.5 db/-0.5 dB) (10?k load) |
| DISPLAY | 4.3" TFT color LCD (480x272) |
| INPUT | Standard mono phone jack |
| Rated input level: -20 dBu | |
| Input impedance (line): 500 ?k | |
| RETURN | Standard mono phone jack |
| Rated input level: -20 dBu | |
| Input impedance (line): 1 ?M | |
| AUX IN | Stereo mini jack |
| Rated input level: -10 dBu | |
| Input impedance (line): 10 ?k |
| OUTPUT R | Standard mono phone jack |
| Maximum output level: +11.4 dBu (when output impedance 10 ?k or higher) | |
| OUTPUT L/MONO (PHONES) | Standard stereo phone jack |
| Maximum output level: +11.4 dBu (when output impedance 10 ?k or higher) | |
| Headphones 24 mW + 24 mW (at 32 load) | |
| SEND | Standard stereo phone jack |
| Maximum output level: +11.4 dBu (when output impedance 10 ?k or higher) |
| INPUT S/N | 123 dB |
| L/R | -99.3 dBu |
| SEND | -99.0 dBu |
| CONTROL INPUT | FP02M input |
| POWER | AC adapter ( 9v DC 500mA, center negative) (Zoom AD-16) |
| USB | Port: USB 2.0 Micro-B/Supported cable type: Micro-B |
| Guitar Lab: USB 1.1 Full Speed | |
| Audio Interface: USB 2.0 Full Speed, 44.1 kHz/32-bit, 2 in, 2 out | |
| - Use a USB cable that supports data transfer. USB bus power is not supported |
| STANDARDS | Cards that support SD/SDXC/SDHC specifications (class 10 or higher) |
| LOOPER | 44.1 kHz/ 16-bit stereo WAV |
| IR | 44.1 - 192kHz, 16/24/32-bit WAV |
| REMOTE | ZOOM BTA-1 or other dedicated wireless adapter |
| EXTERNAL DIMENSIONS | 228 mm (D) x 418 mm (W) x 65 mm (H) |
| WEIGHT | 1.94 kg |
-
